Description

The Scorpio model is like a love-child between a Charvel Desolation DC-1 and an ESP LTD Viper model. With its thin neck and trendy yet aggressive lines, this guitar is perfect for rock and metal.

Full scale super-strat electric guitar building luthier blueprint. Build your own custom guitar with this great digital guitar plan. Make your own templates with the included drawings or use the 2D CAD file for CNC or laser cutting.

With this plan you will get:

3x A0 full-scale PDF drawings

1x full-scale AutoCAD DXF vector file optimized and color-coded for laser cutting.

DXF color legend:
Magenta – Outline cut
Blue – Inside cut
Red – Line engraving
Green – Text engraving

Comes with both Humbucker and Single coil pickup configurations, so you can combine them for your ideal configuration.

Comes with ascending dot inlay fretboard design.
Only the hole centers are shown so you can choose which size of dots you’d like to use.

Further Notes:
– The plan uses standard pickup sizes for the pickup routes, as well as a standard hard tail bridge.
– The controls hole centers shown are based on 1xVol 1xtone 1x3way toggle switch.

You are welcome to use any hardware you choose, just factor those in when you make the templates. A bridge recess will likely be required depending on the bridge you use.

The bolt-on version of this model leaves adequate space around the fretboard heel to allow for body contouring around the horns and neck joint for optimal comfort and upper fret reach.

The design is also further customizable, as any other 24.75″ 24 fret fretboard and headstock outline from our other designs will fit perfectly into this model’s neck pocket. Take note that the actual neck thicknesses and heels differ between models, so ensure that if you combine an actual neck from another model (not just the fretboard and headstock outline), that it is the same neck between both models.

This design can also be used for a through-neck guitar build.

Please note that this is a digital item and not a physical item.
